Targeted RF Energy Delivery
The core of the PINXEL-V’s effectiveness lies in its ability to bypass the epidermis and deliver highly concentrated RF energy directly into the dermis via ultra-fine, 0.2 mm gold-plated microneedles. This process creates controlled thermal zones that stimulate an intense wound-healing response, triggering the sustained synthesis of new collagen and elastin fibers. Because the RF energy is deposited deep beneath the surface, the risk of epidermal damage and Post-Inflammatory Hyperpigmentation (PIH), common with traditional lasers, is dramatically reduced, making it safe for all skin colors. The system operates at a 2MHz frequency with a maximum power of 50watts, allowing for precise control over the coagulation and thermal effect. Adjustable needle depths, ranging from 0.4mm to 4.0mm (in 0.2mm increments), ensure that treatments can be meticulously tailored for shallow, medium, or deep skin concerns across the face and body.The Vacuum Advantage: Boosting Topical Efficacy
What sets PINXEL-V apart is its integrated vacuum system. This dual air chamber design enhances treatment outcomes in two critical ways:- Tissue Engagement: The vacuum gently pulls the skin into the tip, ensuring perfect contact between the microneedles and the target tissue, especially in contoured or delicate areas (like the eyes and neck).
- Enhanced Topical Delivery: As the microneedles retract after creating microchannels and delivering RF energy, the vacuum pressure releases air, effectively pushing topical serums and solutions deeper into the dermis. This mechanism has been shown to increase topical penetration by up to 67% (with specific needle types), significantly amplifying treatment efficacy for conditions like acne scars or stretch marks.
Key Features
- Integrated Vacuum System: Enhances tissue contact, reduces pain, and boosts topical product absorption by up to 67%.
- Ultimate Depth Control: Adjustable needle penetration from 0.4mm to 4.0mm to precisely target various skin layers and concerns.
- Dual RF Handles: Includes a Micro Needle RF handle for invasive treatments and a Fractional RF handle for a non-invasive resurfacing alternative.
- Multiple Needle Options: A comprehensive range of disposable, sterilized tips, including M-types (e.g., M-81) and F-types (e.g., F-9*9), available in Insulated (dermis only, faster recovery) and Non-Insulated (dermis and epidermis, stronger result) options.
- Bi-polar & Mono-polar Modes: Offers Bi-polar RF for precise facial treatments (energy confined to needle depth) and Mono-polar RF for deeper body treatments.
- Enhanced Safety and Comfort: Features gold-plated needles for biocompatibility, a stepping motor for smooth insertion, and an adjustable cooling system (Levels 1-3) to minimize pain.
- Intuitive Operation: Control all parameters via a large, 10.4-inch full-size touchscreen with user-friendly sliding menus and an energy calibration feature for consistent performance.
Technical Specifications & Attachments
| Feature | Specification |
| RF Frequency | 2MHz |
| Maximum Power | 50watts |
| Needle Depth | 0.4mm to 4.0mm (in 0.2mm increments) |
| Needle Thickness | 0.2mm |
| Handle Types | Micro Needle RF, Fractional RF |
| Working Modes | Single/AUTO, Mono-polar, Bi-polar |
| Topical Delivery Boost | Up to 67% (Vacuum-Assisted) |
| Needle Material | Gold-plated, disposable |
| User Interface | 10.4-inch Full-Size Touch Screen |
| Cooling Levels | 1-3 adjustable levels |
Versatile Applications
The PINXEL-V’s flexibility makes it highly effective for a wide spectrum of aesthetic and dermatological indications:- Scars: Significant improvement in acne scars (ice pick, boxcar, rolling), surgical scars, and scars from injury.
- Rejuvenation: Reduction of fine lines and deep wrinkles around the eyes, mouth, and forehead.
- Texture & Pores: Minimizing large pore appearance and achieving overall skin reconstruction and tightening.
- Body Contouring: Effective treatment for stretch marks (striae) and skin laxity on the body (Mono-polar RF).
- Applicable Areas: Face, neck, chest, abdomen, arms, and legs.
A: The vacuum system improves skin contact, ensuring the RF energy is delivered efficiently. Most importantly, as the needles retract, the vacuum pressure assists in pushing topical serums (like growth factors or hyaluronic acid) up to 67% deeper into the microchannels, significantly boosting treatment outcomes.
A: Yes. PINXEL-V is highly safe for all skin types and colors. Since the microneedles deliver the RF energy directly to the dermis, the delicate epidermal melanocytes are largely spared, drastically reducing the risk of Post-Inflammatory Hyperpigmentation (PIH) common with traditional laser treatments.
A: Insulated needles only deliver RF energy from the very tip, treating the dermis while protecting the epidermis. They are less painful and offer faster recovery. Non-Insulated needles treat both the dermis and epidermis, resulting in more intense, but slightly more painful, results with slightly longer downtime.
A: Yes. PINXEL-V includes a Fractional RF handle with non-invasive tips (e.g., F-33, F-55, F-9*9). This mode delivers fractional RF energy through the skin surface without microneedle penetration, offering a gentler, non-invasive option for wrinkle and texture improvement.
A: PINXEL-V is highly effective for reducing the appearance of acne scars, fine lines, and deep wrinkles, stretch marks, enlarged pores, and improving overall skin laxity and texture.
